Upgrade Astro Runtime (Airflow version) on Astronomer Software

Overview​

Regularly upgrading your Software Deployments ensures that your Deployments continue to be supported and that your Airflow instance has the latest features and functionality.

To upgrade your Airflow Deployment to a later version of Airflow:

• Select a new Airflow version with the Software UI or CLI to start the upgrade.
• Change the FROM statement in your project's Dockerfile to reference an Astro Runtime image that corresponds to your current Airflow version.
• Deploy your upgrade to Astronomer.

Available Astronomer image versions​

A cron job automatically pulls new Astronomer image versions from the Astronomer update service and adds them to the Software UI and CLI within 24 hours of their publication. You don't have to upgrade Astronomer to upgrade Airflow.

If you don't want to wait for new Astronomer image versions, you can manually trigger the cron job with the following Kubernetes command:

kubectl create job --namespace astronomer --from=cronjob/astronomer-houston-update-airflow-check airflow-update-check-first-run

If you get a message indicating that a job already exists, delete the job and rerun the command.

Step 1: Review upgrade considerations​

Astro Runtime upgrades can include breaking changes, especially when you're upgrading to a new major version. Check the upgrade considerations for your upgrade version to anticipate any breaking changes or upgrade-specific instructions before you proceed.

Step 2: Start the upgrade process​

Starting the upgrade process doesn't interrupt or otherwise impact your Airflow Deployment. It only signals to Astronomer Software that you intend to upgrade at a later time.

With the Software UI​

1. Go to Deployment > Settings > Basics > Airflow Version.
2. Select an Airflow version.
3. Click Upgrade.

With the Astro CLI​

1. Run astro login <base-domain> to confirm you're authenticated.

2. Run the following command to list your current Deployments.

   astro deployment list


   Copy the ID of the Deployment you want to upgrade.

3. Run the following command to list the available Airflow versions:

   astro deployment airflow upgrade --deployment-id=<deployment-id>


4. Enter the Airflow version you want to upgrade to and press Enter.

Step 3: (Optional) Pin provider package versions​

Major Astro Runtime upgrades can include significant upgrades to built-in provider packages. These package upgrades can sometimes include breaking changes for your DAGs. See the Apache Airflow documentation for a list of all available provider packages and their release notes.

For the most stable upgrade path, Astronomer recommends pinning all provider package versions from your current Runtime version before upgrading.

1. Run the following command to check the version of all provider packages installed in your Astro Runtime version:

   docker run --rm quay.io/astronomer/astro-runtime:<current-runtime-version> pip freeze | grep apache-airflow-providers


2. After reviewing this list, pin the version for each provider package in your Astro project requirements.txt file. For example, Runtime 7.4.1 uses version 4.0.0 of apache-airflow-providers-databricks. To pin this version of the Databricks provider package when you upgrade to a later version of Runtime, you add the following line to your requirements.txt file:

   apache-airflow-providers-databricks==4.0.0


Step 4: (Optional) Run upgrade tests with the Astro CLI​

You can use the Astro CLI to anticipate and address problems before upgrading to a newer version of Astro Runtime. Before you upgrade, run the following command to run tests against the version of Astro Runtime you're upgrading to:

astro dev upgrade-test --runtime-version <upgraded-runtime-version>

The Astro CLI then generates test results in your Astro project that identify dependency conflicts and import errors that you would experience using the new Astro Runtime version. Review these results and make the recommended changes to reduce the risk of your project generating errors after you upgrade. For more information about using this command and the test results, see Test before upgrade your Astro project.

Step 5: Update your Astro project​

1. In your Astro project, open your Dockerfile.

2. Change the Docker image in the FROM statement of your Dockerfile to a new version of Astro Runtime. For example, to upgrade to the latest version of Runtime, you would change the FROM statement in your Dockerfile to:

   FROM quay.io/astronomer/astro-runtime:12.5.0


   For a list of supported Astro Runtime versions, see Astro Runtime maintenance and lifecycle policy.

1. Save the changes to your Dockerfile.

Step 6: Test Astro Runtime locally​

Astronomer recommends testing new versions of Astro Runtime locally to ensure that Airflow starts as expected before upgrading your Deployment on Astro.

1. Open your project directory in your terminal and run astro dev restart. This restarts the Docker containers for the Airflow webserver, scheduler, triggerer, and Postgres metadata database.

2. Access the Airflow UI of your local environment by navigating to http://localhost:8080 in your browser.

3. Confirm that your local upgrade was successful by scrolling to the bottom of any page. You should see your new Astro Runtime version in the footer as well as the version of Airflow it is based on.



4. (Optional) Run DAGs locally to ensure that all of your code works as expected. If you encounter errors after your upgrade, it's possible that your new Astro Runtime version includes a breaking provider package change. If you experience one of these breaking changes, follow the steps in Upgrade or pin provider package versions to check your provider package versions and, if required, pin the provider package version from your previous Runtime version in your requirements.txt file.

Step 7: Deploy to Astronomer​

1. Run the following command to push your upgraded Astro project to your Deployment:

   astro deploy


2. In the Software UI, open your Deployment and click Open Airflow.

3. In the Airflow UI, scroll to the bottom of any page. You should see your new Runtime version in the footer.

Cancel Airflow upgrade​

As a System Admin, you can cancel an Airflow Deployment upgrade at any time if you haven't yet changed the Astronomer Runtime image in your Dockerfile and deployed it.

In the Software UI, select Cancel next to Airflow Version.

Using the Astro CLI, run:

astro deployment airflow upgrade --cancel --deployment-id=<deployment-id>

For example, if you cancel an upgrade from Airflow 2.1.0 to Airflow 2.2.0 in the CLI, the following message appears:

Airflow upgrade process has been successfully canceled. Your Deployment was not interrupted and you are still running Airflow 2.1.0.

Canceling the Airflow upgrade process does not interrupt or otherwise impact your Airflow Deployment or code that's running.

astronomer:
  houston:
    config:
      deployments:
        enableSystemAdminCanCreateDeprecatedAirflows: true

Upgrade considerations​

Consider the following when you upgrade Astro Runtime:

• Astronomer does not support downgrading a Deployment on Astronomer Software to a lower version of Astro Runtime.
• All versions of the Astro CLI support all versions of Astro Runtime. There are no dependencies between the two products.
• Upgrading to certain versions of Runtime might result in extended upgrade times or otherwise disruptive changes to your environment. To learn more, see Version-specific upgrade considerations.

To stay up to date on the latest versions of Astro Runtime, see Astro Runtime release notes. For more information on Astro Runtime versioning and support, see Astro Runtime versioning and lifecycle policy. For a full collection of Astro Runtime Docker images, go to the Astro Runtime repository on Quay.io.

Version upgrade considerations​

Each specific Astro Runtime versions has upgrade considerations that you need to be aware of and account for when you upgrade. These include breaking changes, database migrations, and other considerations.

Runtime 12 (Airflow 2.10)​

Upgrade to Python 3.12​

Starting with Python version 3.12, Python has removed the module imp. This can cause errors for your DAGs if you use imp to access materials using the import statement. Python recommends migrating to importlib instead.

See How do I migrate from imp guidance from Python for remediation steps.

Incompatibility between Git-Sync and Runtime 12.1.0​

Astro Runtime 12.1.0 is incompatible with Git-Sync. Upgrade to Astro Runtime 12.1.1 to use Git-Sync with Astronomer Software.

Runtime 11 (Airflow 2.9)​

Yanked versions of Runtime 11​

Use caution if you create new Deployments or upgrade to the following versions of Runtime 11, which are yanked. These Runtime versions warn you about upgrading to or creating a Deployment with a version that contains a known limitation or bug.

• 11.0.0
• 11.1.0

Bug affecting users running a local Astro Runtime environment​

In Airflow 2.9, a bug affecting custom actions in Airflow plugins (#39421) prevented users from running the Astro Runtime environment locally for Astro Runtime versions 11.0.0, 11.1.0, and 11.2.0. Deployments running these versions on Astro are not affected.

Runtime 9 (Airflow 2.7)​

Connection testing in the Airflow UI disabled by default​

In Airflow 2.7, connection testing in the Airflow UI is disabled by default. Astronomer does not recommend reenabling the feature unless you fully trust all users with edit/ delete permissions for Airflow connections.

To reenable the feature, set the following environment variable in your Astro project Dockerfile:

ENV AIRFLOW__CORE__TEST_CONNECTION=Enabled

Upgrade to Python 3.11​

The base distribution of Astro Runtime 9 uses Python 3.11 by default. Some provider packages, such as apache-airflow-providers-apache-hive, aren't compatible with Python 3.11.

To continue using these packages with a compatible version of Python, upgrade to the Astro Runtime Python distribution for your desired Python version.

Runtime 8 (Airflow 2.6)​

Breaking change to apache-airflow-providers-cncf-kubernetes in version 8.4.0​

Astro Runtime 8.4.0 upgrades apache-airflow-providers-cncf-kubernetes to 7.0.0, which includes a breaking change by removing some deprecated features from KubernetesHook. If you are using any of these features, either pin your current version of apache-airflow-providers-cncf-kubernetes to your requirements.txt file or ensure that you don't use any of the deprecated features before upgrading.

Package dependency conflicts​

Astro Runtime 8 includes fewer default dependencies than previous versions. Specifically, the following provider packages are no longer installed by default:

• apache-airflow-providers-apache-hive
• apache-airflow-providers-apache-livy
• apache-airflow-providers-databricks
• apache-airflow-providers-dbt-cloud
• apache-airflow-providers-microsoft-mssql
• apache-airflow-providers-sftp
• apache-airflow-providers-snowflake

If your DAGs depend on any of these provider packages, add the provider packages to your Astro project requirements.txt file before upgrading. You can also pin specific provider package versions to ensure that none of your provider packages change after upgrading.

Upgrade to Python 3.10​

Astro Runtime 8 uses Python 3.10. If you use provider packages that don't yet support Python 3.10, use one of the following options to stay on Python 3.9:

• Run your tasks using the KubernetesPodOperator or PythonVirtualenvOperator. You can configure the environment that these tasks run in to use Python 3.9.
• Use the astronomer-provider-venv to configure a custom virtual environment that you can apply to individual tasks.

Provider incompatibilities​

There is an incompatibility between Astro Runtime 8 and the following provider packages installed together:

• apache-airflow-providers-cncf-kubernetes==6.1.0
• apache-airflow-providers-google==10.0.0

That can be resolved by pinning apache-airflow-providers-google==10.9.0 or greater in your requirements.txt file.

This incompatibility results in breaking the GKEStartPodOperator. This operator inherits from the KubernetesPodOperator, but then overrides the hook attribute with the GKEPodHook. In the included version of the cncf-kubernetes providers package, the KubernetesPodOperator uses a new method, get_xcom_sidecar_container_resources. This method is present in the KubernetesHook, but not the GKEPodHook. Therefore, when it is called, it causes the task execution to break.

Runtime 6 (Airflow 2.4)​

Smart Sensors were deprecated in Airflow 2.2.4 and removed in Airflow 2.4.0. If your organization still uses Smart Sensors, you need to start using deferrable operators. See Deferrable operators.

Runtime 5 (Airflow 2.3)​

Astro Runtime 5.0.0, based on Airflow 2.3, includes changes to the schema of the Airflow metadata database. When you first upgrade to Runtime 5.0.0, consider the following:

• Upgrading to Runtime 5.0.0 can take 10 to 30 minutes or more depending on the number of task instances that have been recorded in the metadata database throughout the lifetime of your Deployment on Astro.

• After you upgrade successfully to Runtime 5, you might see errors in the Airflow UI that warn you of incompatible data in certain tables of the database. For example:

  Airflow found incompatible data in the `dangling_rendered_task_instance_fields` table in your metadata database, and moved...


  These warnings have no impact on your tasks or DAGs and can be ignored. If you want to remove these warning messages from the Airflow UI, reach out to Astronomer support. If requested, Astronomer can drop incompatible tables from your metadata database.

For more information on Airflow 2.3, see "Apache Airflow 2.3.0 is here" or the Airflow 2.3.0 changelog.
